Sany series mini rotary drilling rig-DR-60 model

YAHE MODEL
(3)
(35)
(36)
(45)
SANY series rotary drilling rig / Sany series mini rotary drilling rig-DR-60 model

Sany series mini rotary drilling rig-DR-60 model

Drilling diameter
350-800mm
Drilling depth
5-15m
Machine weight
8-10ton
Working height
5.4m
Contacta con nosotros Enviar consulta
Model DR-60
Machine weight 10T
Maxmum drilling depth 15m
Drilling diameter 500-1200mm
Engine brand kuboya/isuzu(optional)
Engine rated power 36kw
Maximum lifting force of pressurization system 100kn
Maximum lifting force of auxiliary winch 13kn
Working status length*width*height 4800*2000*5400mm
Transport  status length*width*height 4800*2000*3400mm
Maximum torque of power head 60kn.m
Tail swing radius 2300mm
01

uses

Suitable for construction in small and compact spaces, as well as in height restricted areas

02

cold and heat

enhanced top guardrail and extreme weather warning provide double protection.

03

Economy and fuel saving

powerful, reliable and durable, low fuel consumption and low operating cost.

04

Autonomous driving

equipped with wireless radio and remote control driving system, easy to transition.
